5131.B

EAN: 8024482191454

The new 5116 and 5131 models can be stacked with each other and/or on top of the Explorer 5140, the popular tool chest with drawers, creating a mobile workstation with even greater loading capacity for tools, spare parts and large components, also sharing with the latter its trolley system with wheels and telescopic handle. Folding handle in the top lid for easier carrying.

Models

5131.B E

black empty

5131.B

black w/pre-cubed foam
  • Technical Specifications
  • Features
  • Accessories
Internal dimensions

L Length 20 5/6 in

W Width 11 5/8 in

D Depth 12 3/16 in

Lid 2 3/8 in

Base 9 13/16 in

External dimensions

L Length 23 1/16 in

W Width 14 1/2 in

D Depth 13 11/16 in

Other data

Weight Empty 10.58 lbs

Weight With Foam 13.22 lbs

Weight With Custom Foam lbs

Volume 12.49 gal

Bouyancy lbs/max

Operating Temperature °F min -27.4 / max 194

Internal dimensions

L Length 516 mm

W Width 296 mm

D Depth 310 mm

Lid 60 mm

Base 250 mm

External dimensions

L Length 585 mm

W Width 386 mm

D Depth 348 mm

Other data

Weight Empty 4.8 Kg

Weight With Foam 6 Kg

Weight With Custom Foam Kg

Volume 47.3 lt

Bouyancy Kg/max

Operating Temperature °C min -33 / max 90

PULL RELEASE LATCH

PULL RELEASE LATCH

New pull release latch grants additional safety and avoids accidental opening

CORROSION PROOF METAL HINGES WITH LID STAY FEATURES

CORROSION PROOF METAL HINGES WITH LID STAY FEATURES

INTERNAL SLOTS

INTERNAL SLOTS

Internal slots for optional panel mounting brackets or panel mounting rings

SEALING O-RING

SEALING O-RING

(Art. NEOSEAL + nr. art.)O-RING

PVC WATERPROOF I. D. REMOVABLE LABEL

PVC WATERPROOF I. D. REMOVABLE LABEL

(Art. LABELCOVER + nr. art.)

LID CAN BE SET TO SLIDE-OFF

LID CAN BE SET TO SLIDE-OFF

By releasing the back screw, lid becomes set to slide-off when opened at 70°

SOFT GRIP RUBBER HANDLE

SOFT GRIP RUBBER HANDLE

Load tested handle, reinforced with corrosion proof steel pins

STAINLESS STEEL REINFORCED PADLOCKABLE POINTS

STAINLESS STEEL REINFORCED PADLOCKABLE POINTS

4 stainless steel clip-covers on the two frontal outer padlock points, to grant a better resistance to abrasion.

ABILITY TO STACK

ABILITY TO STACK

The special design of the bottom and the lid feet, grants a perfect stackability.

AUTOMATIC PURGE VALVE

AUTOMATIC PURGE VALVE

Automatic pressure release valve.

Mod. EXPL PADLOCK

Mod. EXPL PADLOCK

PATENTED HEAVY DUTY BRASS PADLOCK WITH KEYS

Mod. EXPL COMBILOCK

Mod. EXPL COMBILOCK

PATENTED COMBINATION PADLOCK

Mod. KIT.EXPL.PLUGS

Mod. KIT.EXPL.PLUGS

BLIND INSERT

Mod. EXPL TSA.DIGILOCK

Mod. EXPL TSA.DIGILOCK

TSA APPROVED PADLOCK WITH COMBINATION

Mod. KIT SUPP.EXPL.

Mod. KIT SUPP.EXPL.

METAL BRACKET - KIT SUPP. EXPL

Mod. KIT SUPP.PLAST.

Mod. KIT SUPP.PLAST.

PLASTIC BRACKET

Download
Product data sheet condensed
Product data sheet complete
High res. picture: case open
High res. picture: case closed
Certifications
Certificate 5131 - IP67-DS-ST ENG
